Fire Fighting Gauge

Fire Fighting Gauge Specification

Operating Pressure
Up to 21 kg/cm

Control Type
Manual

Coating Type
Brass Chrome Plated

Coverage Area
Monitors localized fire extinguisher pressure, not area-specific

Shape
Round

Fire Extinguisher Type
ABC, CO2, DCP

Installation Type
Threaded Mount, Panel Mounted

Technology
Mechanical Analog Gauge

Connectivity Type
Analog/Mechanical, Non-digital

Fire Class
Class A, B, C

Working Temperature
-20C to +60C

Features
Clear dial, corrosion resistant, accurate reading, vibration resistant

Mounting Type
Rear or Bottom Threaded Mount

Application
Fire Safety, Fire Suppression Systems

Diameter
63 mm

Capacity
Compatible with 1 kg to 10 kg Extinguishers

Pressure
0-21 kg/cm (0-300 psi)

Dial Type
Color coded (Green, Red, Yellow Zones)

Display Type
Analog Needle

Accuracy
±1.6% FSD

Weight
Approx. 120g

Protection Class
IP44

Thread Size
1/8" or 1/4" BSP

Material
Brass Body with Glass Front

Fluid Type
Dry Air or Nitrogen

Fire Fighting Gauge Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
2 Units Per Week

Delivery Time
10-15 Days

About Fire Fighting Gauge

We are one of the emerging suppliers of the global market, presenting a huge collection of Fire fighting Gauge to our precious clients.

Features:

Accurate readings

Compact design

Optimum quality

Diaphragm/ Automatic/ Boundan Type

Excellent Finish

Reliable and Accurate Pressure Monitoring

The mechanical analog gauge employs a color-coded dial for quick pressure status assessment, offering 1.6% FSD accuracy. Its analog connectivity and vibration-resistant design ensure reliable operation in emergency situations, enabling users to make informed decisions instantly.

Durable and Versatile Construction

The brass chrome-plated casing, with a glass front, provides excellent corrosion resistance and robustness. Its IP44 protection ensures functionality across a wide range of temperatures, making it ideal for use in different fire safety environments, including suppression system panels.

FAQs of Fire Fighting Gauge:

Q: How do I install this fire fighting gauge onto my extinguisher system?

A: Installation is straightforward: Use the appropriate threaded connection (1/8" or 1/4" BSP) to mount the gauge onto the extinguisher or panel, ensuring a secure and leak-free fit. The design supports both rear and bottom mounting for added flexibility.

Q: What type of extinguishers is this gauge compatible with?

A: This gauge is suitable for use with various ABC, CO2, and DCP fire extinguishers that have a capacity ranging from 1 kg to 10 kg. It efficiently monitors the pressure for enhanced fire safety assurance.

Q: When should I replace or service my fire fighting gauge?

A: It is recommended to inspect the gauge regularly for any signs of damage or inaccuracy, especially after each use or during scheduled maintenance of the fire extinguisher system. Replace the gauge if inaccurate readings or physical defects are observed.

Q: Where can this gauge be used within fire suppression systems?

A: This gauge is ideal for panel-mounted installations in fire suppression systems, providing localized pressure monitoring for extinguishers in industrial, commercial, and institutional environments across India.

Q: What are the benefits of the color-coded dial feature?

A: The color-coded dial (green, red, yellow zones) allows users to quickly assess pressure status, helping ensure the extinguisher is always within operational range and ready for emergency use.

Q: How does the gauge ensure durability and longevity?

A: With its brass chrome-plated body, glass front, and IP44 protection, the gauge offers excellent resistance to corrosion, vibration, and environmental factors, ensuring long-term reliability in diverse settings.

Q: What fluid types can this gauge monitor, and what is its pressure range?

A: The gauge is designed to work with dry air or nitrogen, supporting an operating pressure of up to 21 kg/cm (0-300 psi), suitable for most standard fire extinguishers.
